TELEMECANIQUE SENSORS - XUK2LAPSMM12R - Photoelectric sensors XU, photo electric laser sensor, XUK, thru beam receiver, Sn 30 m, 10...30 VDC, M12
Lei 847.00
Lei 700.00
In stock
SKU
XUK2LAPSMM12R
Free shipping for orders over 1000 lei
Free shipping applies to cities without additional kilometers or heavy/high volume products
Photoelectric sensors XU, photo electric laser sensor, XUK, thru beam receiver, Sn 30 m, 10...30 VDC, M12
Main
| Range of product | Telemecanique Photoelectric sensors XU |
|---|---|
| Series name | Application assembly Application material handling |
| Electronic sensor type | Photo-electric sensor |
| Sensor name | XUK |
| Sensor design | Compact 50 x 50 |
| Detection system | Thru beam |
| Material | Plastic |
| Type of output signal | Discrete |
| Supply circuit type | DC |
| Wiring technique | 4-wire |
| Discrete output type | PNP |
| Discrete output function | 1 NO or 1 NC programmable |
| Electrical connection | 1 male connector M12, 4 pins |
| Product specific application | Not applicable |
| Emission | Red thru beam |
Complementary
| Enclosure material | ABS/PC |
|---|---|
| Lens material | PMMA |
| Output type | Solid state |
| Add on output | Without |
| Status LED | 1 LED (green) for supply on, 1 LED (yellow) for output state, 1 LED (red) for alignment assistance |
| [Us] rated supply voltage | 12...24 V DC with reverse polarity protection |
| Maximum voltage drop | <2.4 V (closed state) |
| Switching capacity in mA | <= 100 mA (overload and short-circuit protection) |
| Current consumption | <= 30 mA no-load |
| Delay first up | 300 MILLISECOND |
| Delay response | 0.14 MILLISECOND |
| Setting-up | Using teach button or remote teaching |
| Delay recovery | 0.14 MILLISECOND |
Environment
| Vibration resistance | 7 gn, amplitude = +/- 1.5 mm (f = 10-55 Hz) conforming to IEC 60068-2-6 |
|---|---|
| Shock resistance | 30 gn (duration = 11 ms) conforming to IEC 60947-5-2 |
| IP degree of protection | IP67 conforming to IEC 60529, IP69K conforming to DIN 40050 |
Packing Units
| Unit type of package 1 | PCE |
|---|---|
| Number of units in package 1 | 1 |
| Package 1 height | 3 CENTIMETER |
| Package 1 width | 6 CENTIMETER |
| Package 1 length | 10 CENTIMETER |
| Package 1 weight | 0.032 KILOGRAM |
| Unit type of package 2 | S01 |
| Number of units in package 2 | 28 |
| Package 2 height | 15 CENTIMETER |
| Package 2 width | 15 CENTIMETER |
| Package 2 length | 40 CENTIMETER |
| Package 2 weight | 1.544 KILOGRAM |
| Indivisible sale quantity | 1 |
Documents & Downloads
Write Your Own Review
| Manufacturer | TELEMECANIQUE SENSORS |
|---|---|
| Manufacturer code | XUK2LAPSMM12R |
| Order Unit | Pce |
