TELEMECANIQUE SENSORS - XMPC06C2941S701 - Pressure switch XMP, 6 bar, G 1/2, zinc alloy, sea water 70 °C, cable gland, knurled knob adjustment, IP65
Lei 386.00
Lei 319.01
In stock
SKU
XMPC06C2941S701
Free shipping for orders over 1000 lei
Free shipping applies to cities without additional kilometers or heavy/high volume products
Pressure switch XMP, 6 bar, G 1/2, zinc alloy, sea water 70 °C, cable gland, knurled knob adjustment, IP65
This variant: fluid connection: G 1/2 (female) conforming to ISO 228; materials in contact with fluid: Canvas covered nitrile chromated zinc alloy; controlled fluid: Air (0-70 °C), fresh water (0-70 °C), sea water (0-70 °C); electrical connection: Screw-clamp terminals, clamping capacity: minimum : 2 x 4 mm²; cable entry: 2 entries incorporating Pg 16 plastic cable gland, cable outer diameter: 12-15 mm conforming to NF C 68-300; contacts: 3 NC snap action.
Main
| Range of product | Telemecanique Pressure sensors XM |
|---|---|
| Pressure sensor type | Electromechanical pressure sensor |
| Pressure sensor name | XMP |
| Fluid connection type | G 1/2 (female) conforming to ISO 228 |
| Controlled fluid | Air (0-70 °C), fresh water (0-70 °C), sea water (0-70 °C) |
| Cable entry | 2 entries incorporating Pg 16 plastic cable gland, cable outer diameter: 12-15 mm conforming to NF C 68-300 |
| Contacts type and composition | 3 NC snap action |
| Product specific application | Not applicable |
| Pressure switch type of operation | Regulation between 2 thresholds |
| Electrical connection | Screw-clamp terminals, clamping capacity: minimum : 2 x 4 mm² |
| Electrical circuit type | Power circuit |
| Scale type | Adjustable differential |
| Local display | Without |
Complementary
| Type of decompression valve | Without |
|---|---|
| Control type | ON/OFF knob |
| Terminal block type | 6 terminals |
| Pressure actuator | Diaphragm |
| Materials in contact with fluid | Canvas covered nitrile chromated zinc alloy |
| Enclosure material | PA impregnated with fibreglass |
| Operating position | Any position |
| Operating rate | 10 CYCLE_PER_MINUTE |
| Resistance across terminals | 25 MOhm conforming to IEC 60255-7 category 3, 25 MOhm conforming to NF C 93-050 method A |
| Setting | Knurled knob and nut |
| Terminals description ISO n°1 | (1-2)NC (3-4)NC (5-6)NC |
Environment
| Product certifications | EAC |
|---|---|
| Standards | CE IEC 60947-4-1 |
| Vibration resistance | 3 gn conforming to IEC 60068-2-6 (f = 10-500 Hz) |
| Shock resistance | 50 gn conforming to IEC 60068-2-27 |
| Electrical shock protection class | Class I conforming to IEC 60536 |
| IP degree of protection | IP65 conforming to IEC 60529 |
Packing Units
| Unit type of package 1 | PCE |
|---|---|
| Number of units in package 1 | 1 |
| Package 1 height | 6.2 CENTIMETER |
| Package 1 width | 11.4 CENTIMETER |
| Package 1 length | 16.8 CENTIMETER |
| Package 1 weight | 0.554 KILOGRAM |
| Unit type of package 2 | S06 |
| Number of units in package 2 | 100 |
| Package 2 height | 15 CENTIMETER |
| Package 2 width | 15 CENTIMETER |
| Package 2 length | 40 CENTIMETER |
| Package 2 weight | 1.9 KILOGRAM |
| Indivisible sale quantity | 1 |
Documents & Downloads
Write Your Own Review
| Manufacturer | TELEMECANIQUE SENSORS |
|---|---|
| Manufacturer code | XMPC06C2941S701 |
| Order Unit | Pce |
