TELEMECANIQUE SENSORS - XMPA06C2344N07 - Pressure switch XMP, 6 bar, 3 NC, zinc alloy, sea water 70 °C, knurled knob adjustment, IP54, special version N07
Lei 407.00
Lei 336.36
In stock
SKU
XMPA06C2344N07
Free shipping for orders over 1000 lei
Free shipping applies to cities without additional kilometers or heavy/high volume products
Pressure switch XMP, 6 bar, 3 NC, zinc alloy, sea water 70 °C, knurled knob adjustment, IP54, special version N07
This variant: materials in contact with fluid: Canvas covered nitrile chromated zinc alloy; controlled fluid: Air (0-70 °C), fresh water (0-70 °C), sea water (0-70 °C); electrical connection: Screw-clamp terminals, clamping capacity: minimum : 2 x 4 mm²; contacts: 3 NC snap action.
Main
| Range of product | Telemecanique Pressure sensors XM |
|---|---|
| Pressure sensor type | Electromechanical pressure sensor |
| Pressure sensor name | XMP |
| Controlled fluid | Air (0-70 °C), fresh water (0-70 °C), sea water (0-70 °C) |
| Contacts type and composition | 3 NC snap action |
| Product specific application | Not applicable |
| Pressure switch type of operation | Regulation between 2 thresholds |
| Electrical connection | Screw-clamp terminals, clamping capacity: minimum : 2 x 4 mm² |
| Electrical circuit type | Power circuit |
| Scale type | Adjustable differential |
| Local display | Without |
Complementary
| Type of decompression valve | Without |
|---|---|
| Control type | Without |
| Terminal block type | 6 terminals |
| Pressure actuator | Diaphragm |
| Materials in contact with fluid | Canvas covered nitrile chromated zinc alloy |
| Enclosure material | PA impregnated with fibreglass |
| Operating position | Any position |
| Operating rate | 10 CYCLE_PER_MINUTE |
| Resistance across terminals | 25 MOhm conforming to IEC 60255-7 category 3, 25 MOhm conforming to NF C 93-050 method A |
| Setting | Knurled knob and nut |
| Terminals description ISO n°1 | (1-2)NC (3-4)NC (5-6)NC |
Environment
| Standards | CE IEC 60947-4-1 |
|---|---|
| Vibration resistance | 3 gn conforming to IEC 60068-2-6 (f = 10-500 Hz) |
| Shock resistance | 50 gn conforming to IEC 60068-2-27 |
| Electrical shock protection class | Class I conforming to IEC 60536 |
| IP degree of protection | IP54 conforming to IEC 60529 |
Packing Units
| Unit type of package 1 | PCE |
|---|---|
| Number of units in package 1 | 1 |
| Package 1 height | 6.5 CENTIMETER |
| Package 1 width | 11.5 CENTIMETER |
| Package 1 length | 17 CENTIMETER |
| Package 1 weight | 0.5 KILOGRAM |
| Unit type of package 2 | S03 |
| Number of units in package 2 | 20 |
| Package 2 height | 30 CENTIMETER |
| Package 2 width | 30 CENTIMETER |
| Package 2 length | 40 CENTIMETER |
| Package 2 weight | 0.01 KILOGRAM |
| Unit type of package 3 | CAR |
| Number of units in package 3 | 1 |
| Package 3 height | 6.5 CENTIMETER |
| Package 3 width | 17 CENTIMETER |
| Package 3 length | 11.5 CENTIMETER |
| Package 3 weight | 0.5 KILOGRAM |
| Indivisible sale quantity | 1 |
Write Your Own Review
| Manufacturer | TELEMECANIQUE SENSORS |
|---|---|
| Manufacturer code | XMPA06C2344N07 |
| Order Unit | Pce |
