TELEMECANIQUE SENSORS - XMPA06B2133NS1 - Pressure sensors XM, Pressure sensor switch, 6 Bar G 1/4 femal
Lei 208.00
Lei 171.90
In stock
SKU
XMPA06B2133NS1
Free shipping for orders over 1000 lei
Free shipping applies to cities without additional kilometers or heavy/high volume products
Pressure sensors XM, Pressure sensor switch, 6 Bar G 1/4 femal
Main
| Range of product | Telemecanique Pressure sensors XM |
|---|---|
| Pressure sensor type | Electromechanical pressure sensor |
| Pressure sensor name | XMP |
| Controlled fluid | Air (0-70 °C), fresh water (0-70 °C), sea water (0-70 °C) |
| Contacts type and composition | 2 NC snap action |
| Product specific application | Not applicable |
| Pressure switch type of operation | Regulation between 2 thresholds |
| Electrical connection | Screw-clamp terminals, clamping capacity: minimum : 2 x 4 mm² |
| Electrical circuit type | Power circuit |
| Scale type | Adjustable differential |
| Local display | Without |
Complementary
| Type of decompression valve | Without |
|---|---|
| Control type | Without |
| Terminal block type | 4 terminals |
| Pressure actuator | Diaphragm |
| Materials in contact with fluid | Canvas covered nitrile chromated zinc alloy |
| Enclosure material | PA impregnated with fibreglass |
| Operating position | Any position |
| Operating rate | 10 CYCLE_PER_MINUTE |
| Resistance across terminals | 25 MOhm conforming to IEC 60255-7 category 3, 25 MOhm conforming to NF C 93-050 method A |
| Setting | Nut |
| Terminals description ISO n°1 | (1-2)NC (3-4)NC |
Environment
| Standards | CE IEC 60947-4-1 |
|---|---|
| Vibration resistance | 3 gn conforming to IEC 60068-2-6 (f = 10-500 Hz) |
| Shock resistance | 50 gn conforming to IEC 60068-2-27 |
| Electrical shock protection class | Class I conforming to IEC 60536 |
| IP degree of protection | IP54 conforming to IEC 60529 |
Packing Units
| Unit type of package 1 | PCE |
|---|---|
| Number of units in package 1 | 1 |
| Package 1 height | 5.9 CENTIMETER |
| Package 1 width | 11.6 CENTIMETER |
| Package 1 length | 9.7 CENTIMETER |
| Package 1 weight | 0.449 KILOGRAM |
| Unit type of package 2 | CAR |
| Number of units in package 2 | 10 |
| Package 2 height | 10 CENTIMETER |
| Package 2 width | 30 CENTIMETER |
| Package 2 length | 27 CENTIMETER |
| Package 2 weight | 4.646 KILOGRAM |
| Unit type of package 3 | S06 |
| Number of units in package 3 | 100 |
| Package 3 height | 73.5 CENTIMETER |
| Package 3 width | 60 CENTIMETER |
| Package 3 length | 80 CENTIMETER |
| Package 3 weight | 59.46 KILOGRAM |
| Indivisible sale quantity | 10 |
Documents & Downloads
Write Your Own Review
| Manufacturer | TELEMECANIQUE SENSORS |
|---|---|
| Manufacturer code | XMPA06B2133NS1 |
| Order Unit | Pce |
