TELEMECANIQUE SENSORS - XEP4E1FDA326 - Microswitch, Limit switches XC Standard, miniature limit switch, flat lever, cable length 0.5 m
Lei 94.00
Lei 77.69
In stock
SKU
XEP4E1FDA326
Free shipping for orders over 1000 lei
Free shipping applies to cities without additional kilometers or heavy/high volume products
Microswitch, Limit switches XC Standard, miniature limit switch, flat lever, cable length 0.5 m
Main
| Range of product | OsiSense XC |
|---|---|
| Series name | Special format |
| Product or component type | Microswitch |
| Device short name | XEP4 |
| Detector design | Subminiature, DIN 41635 B format, sealed |
| Head type | Plunger head |
| Lever material | Stainless steel |
| Lever fixing position | A |
| Movement of operating head | Linear |
| Type of operator | Flat lever |
| Type of approach | Lateral approach |
| Electrical connection | Pre-cabled |
| Cable composition | 3 x 0.5 mm² |
| Contacts type and composition | 1 C/O standard |
| Contact operation | Snap action |
| Contacts material | AgCdO |
Complementary
| Body material | Polyester |
|---|---|
| Contact code designation | B300, AC-15 (Ue = 240 V, Ie = 1.5 A) conforming to IEC 60947-5-1 appendix A, R300, DC-13 (Ue = 250 V, Ie = 0.1 A) conforming to IEC 60947-5-1 appendix A |
| Terminals description ISO n°1 | (1-2-4)OC |
Environment
| IP degree of protection | IP67 |
|---|---|
| Marking | CE |
| Standards | CURus IEC 60947-5-1 IEC 61058 UL 1054 |
Packing Units
| Unit type of package 1 | PCE |
|---|---|
| Number of units in package 1 | 1 |
| Package 1 height | 1.5 CENTIMETER |
| Package 1 width | 7 CENTIMETER |
| Package 1 length | 12 CENTIMETER |
| Package 1 weight | 0.016 KILOGRAM |
| Unit type of package 2 | S01 |
| Number of units in package 2 | 100 |
| Package 2 height | 15 CENTIMETER |
| Package 2 width | 15 CENTIMETER |
| Package 2 length | 40 CENTIMETER |
| Package 2 weight | 1.877 KILOGRAM |
| Unit type of package 3 | BAG |
| Number of units in package 3 | 5 |
| Package 3 height | 3 CENTIMETER |
| Package 3 width | 7 CENTIMETER |
| Package 3 length | 12 CENTIMETER |
| Package 3 weight | 0.085 KILOGRAM |
| Indivisible sale quantity | 1 |
Documents & Downloads
Write Your Own Review
| Manufacturer | TELEMECANIQUE SENSORS |
|---|---|
| Manufacturer code | XEP4E1FDA326 |
| Order Unit | Pce |
