TELEMECANIQUE SENSORS - XCSDMC59010EX - Coded magnetic switch, Telemecanique Safety switches XCS, XCSDMC, 1 NC+1 NO, staggered, cable 10 m
Lei 787.00
Lei 650.41
In stock
SKU
XCSDMC59010EX
Free shipping for orders over 1000 lei
Free shipping applies to cities without additional kilometers or heavy/high volume products
Coded magnetic switch, Telemecanique Safety switches XCS, XCSDMC, 1 NC+1 NO, staggered, cable 10 m
Main
| Range of product | Telemecanique Safety switches XCS |
|---|---|
| Product or component type | Coded magnetic switch |
| Device short name | XCSDMC |
| Material | Plastic |
| Contacts type and composition | 1 NC + 1 NO |
| Contact operation | Staggered |
| Electrical connection | Pre-cabled |
| Cable composition | 4 x 0.25 mm² |
| Design | Rectangular, compact |
| Size | 51 x 16 x 7 mm |
Complementary
| Approach directions | 3 directions |
|---|---|
| [Ue] rated operational voltage | - |
| [Ie] rated operational current | 100 MILLIAMPERE |
| Contacts material | Rhodium |
| Switching capacity in mA | 0.1...100 mA |
| Insulation resistance | 1000 MOhm |
| Switching frequency | 150 Hz |
Environment
| Safety level | - |
|---|---|
| Safety reliability data | - |
| Protective treatment | TH |
| Vibration resistance | 10 gn (f= 10-150 Hz) conforming to IEC 60068-2-6 |
| Shock resistance | 30 gn for 11 ms conforming to IEC 60068-2-27 |
| Sensitivity to magnetic fields | 0.3 MILLITESLA |
| Electrical shock protection class | Class II conforming to IEC 60536 |
| IP degree of protection | IP66 conforming to IEC 60529, IP67 conforming to IEC 60529 |
| Enclosure material | Thermoplastic PBT |
| Cable material | PVC |
| Dust zone | According to protection mode mD, tD and ia zone 0 - 1 - 2/20 - 21 - 22 |
| Product certifications | INERIS 07ATEX0036 |
| Standards | EN 60079-11 EN 60079-18 IEC 60079-0 IEC 60079-31 ISO 13849-1 |
| Directives | 2014/34/EU - ATEX directive |
Packing Units
| Unit type of package 1 | PCE |
|---|---|
| Number of units in package 1 | 1 |
| Package 1 height | 5.4 CENTIMETER |
| Package 1 width | 17.1 CENTIMETER |
| Package 1 length | 19.7 CENTIMETER |
| Package 1 weight | 0.41 KILOGRAM |
| Unit type of package 2 | S02 |
| Number of units in package 2 | 10 |
| Package 2 height | 15 CENTIMETER |
| Package 2 width | 30 CENTIMETER |
| Package 2 length | 40 CENTIMETER |
| Package 2 weight | 4.386 KILOGRAM |
| Indivisible sale quantity | 1 |
Documents & Downloads
Write Your Own Review
| Manufacturer | TELEMECANIQUE SENSORS |
|---|---|
| Manufacturer code | XCSDMC59010EX |
| Order Unit | Pce |
