FINDER - 34.51.7.005.0010 - Ultra-slim PCB relay 1 CO (SPDT), 6 A, 5 V DC sensitive coil, AgNi, flux proof RT II

This variant: 34.51.7.005.0010 — Sensitive DC, CO (SPDT), Electromechanical type, 5 V, AgNi, Flux proof (RT II), 1 pole, 6 A

Type 34.51 ultra-slim electromechanical PCB relays, 6 A, 5 mm width, low absorption coil and suitable for PCB mounting or socket mounting using the 93 Series sockets.

Available version 34.51-5010 with contact AgNi+AU.

Features include:

• 1 changeover contact or 1 normally open contact
• Ultra-slim, 5mm wide
• Sensitive DC coil – 170 mW (possibility of AC/DC power supply with 93 Series sockets)
• UL Listing (relay/socket/jumper link)
• Cadmium-free contacts
• 8/8 mm clearance/sliding distance
• 6 kV (1.2/50 μs) insulation between coil and contacts

Documentation:

• Technical datasheet
• Declaration of conformity
