FINDER - 20.23.9.012.0000 - Modular step relay 12 V, AgNi, Double phase switch 1 NC+1 NO (SPST-NO+SPST-NC), DC, 35 mm rail (EN 60715) mount, Standard
Lei 194.00
Lei 160.33
In stock
Only 1 left
SKU
FI202390120000
Free shipping for orders over 1000 lei
Free shipping applies to cities without additional kilometers or heavy/high volume products
Modular step relay 12 V, AgNi, Double phase switch 1 NC+1 NO (SPST-NO+SPST-NC), DC, 35 mm rail (EN 60715) mount, Standard
This variant: 20.23.9.012.0000 — DC, 12 V, AgNi, Standard, Double phase switch 1 NC+1 NO (SPST-NO+SPST-NC), 35 mm rail (EN 60715) mount
Type 20.23 Modular step relays, 16A, double phase switch 1 NO + 1 NC, 35 mm rail (EN 60715) mounting.
Features include:
- Width: one module 17.4 mm
- Test button and mechanical indicator
- 7 sequences
- AC or DC coil
- Identification card
- Connection with illuminated pushbuttons via the Type 026.00 adaptor
- Cadmium-free contacts
Documentation:
Write Your Own Review
| Manufacturer | FINDER |
|---|---|
| Manufacturer code | 20.23.9.012.0000 |
| Order Unit | Pce |
| Series | 20 |
| Supply voltage | 12 V DC |
| Device type | Modular step relay |
| Contact material | AgNi |
| Country of origin | Italy |
