FINDER - 20.22.8.110.0000 - Modular step relay 110 V, AgNi, Double phase switch 2 NO (DPST-NO), AC (50/60 Hz), 35 mm rail (EN 60715) mount, Standard
Lei 194.00
Lei 160.33
In stock
Only 6 left
SKU
FI202281100000
Free shipping for orders over 1000 lei
Free shipping applies to cities without additional kilometers or heavy/high volume products
Modular step relay 110 V, AgNi, Double phase switch 2 NO (DPST-NO), AC (50/60 Hz), 35 mm rail (EN 60715) mount, Standard
This variant: 20.22.8.110.0000 — AC (50/60 Hz), 110 V, AgNi, Standard, Double phase switch 2 NO (DPST-NO), 35 mm rail (EN 60715) mount
Type 20.22 Modular step relays, 16A, double phase switch, 35 mm rail (EN 60715) mounting.
Features include:
- Width: one module 17.4 mm
- Test button and mechanical indicator
- 7 sequences
- AC or DC coil
- Identification label
- Connection with illuminated pushbuttons via the Type 026.00 adaptor.
- Cadmium-free contacts
Documentation:
Write Your Own Review
| Manufacturer | FINDER |
|---|---|
| Manufacturer code | 20.22.8.110.0000 |
| Order Unit | Pce |
| Series | 20 |
| Supply voltage | 110 V AC (50/60 Hz) |
| Device type | Modular step relay |
| Contact material | AgNi |
| Country of origin | Italy |
