FINDER - 40.61.9.024.0000 - Miniature PCB relay CO (nPDT), 24 V, Standard, 1 pole, 16 A, AgNi, DC, P.C.B./plug-in - 5mm pinning
Lei 25.73
Lei 21.26
In stock
Only 4 left
SKU
FI406190240000
Free shipping for orders over 1000 lei
Free shipping applies to cities without additional kilometers or heavy/high volume products
Miniature PCB relay CO (nPDT), 24 V, Standard, 1 pole, 16 A, AgNi, DC, P.C.B./plug-in - 5mm pinning
This variant: 40.61.9.024.0000 — DC, CO (nPDT), P.C.B./plug-in - 5mm pinning, 24 V, AgNi, Standard, 1 pole, 16 A
Type 40.61 1 pole relay for direct PCB or 95 Series socket mount.
Features include:
- 5.0 mm pin pitch
- Direct PCB or 95 Series socket mount
- Pin length 3.5 mm for direct PCB mount
- Cadmium-free contact material available
- Meets EN 60335-1 glow wire requirements
- Environmental protection:
– RT II – flux proof (Standard)
– RT III – wash tight (Option)
Documentation:
Write Your Own Review
| Manufacturer | FINDER |
|---|---|
| Manufacturer code | 40.61.9.024.0000 |
| Order Unit | Pce |
| Series | 40 |
| Supply voltage | 24 V DC |
| Switching current | 1 pole, 16 A |
| Device type | Miniature PCB relay |
| Mounting Type | P.C.B./plug-in - 5mm pinning |
| Contact material | AgNi |
| Country of origin | Italy |
